- Make McConaghy
- Model Panther 56
- Year 2026
- LOA 56ft/17m
- Class Multihull
- Hull Carbon Fibre
- Keel Multi-Hull
- Rig Sloop
- Engine Twin Electric
- Drive Sail Drive
- Layout Aft Cockpit
- Berths 8
- Cabins 4
- Aft Cabins 2
- Ancasta Ref 45909
McConaghy Panther 56 For Sale | 2026
2,460,000 Tax Not Paid
Your account cannot save boats.
Following the announcement of the Panther 48 the range has been extended to include the Panther 56. Designed to merge sustainability with cutting-edge performance, these yachts promise to redefine your adventures on the open water, offering exhilarating speed and unmatched agility in a lightweight vessel.
Layout Main Deck
Layout Main Deck
Layout Lower Deck
Layout Lower Deck
PANTHER 56
BUILDER: McConaghy Boat Company
DESIGNER: McConaghy Boat Company
Build Year 2026
CE Category A
CONSTRUCTION:
Composite engineering approved by ASTA
Full carbon hull, deck and structure. Controlled vacuum infusion process with pressed panels carbon and Corecell foam core.
Hull outboard topside and forward inboard sides covered with satin black finished solar panels
Hull shear painted in metallic silver
Hull bottom antifoul (black) roller finished
Side decks covered with nonslip white finish solar panels
Foredeck, Aft deck and stairs covered with EVA foam
Cabin Top- Port & Stbd covered with black finish solar panels, Center covered with satin black solar panels
Cabin Top edge painted in high quality two pack polyurethane coating in metallic silver
Carbon longeron with integrated anchoring system
Dagger boards Carbon composite straight shape with manual purchase system for lifting
Twin balanced spade rudders with self aligning bearings, rope & chain steering, emergency tiller
INTERIOR
All joinery is custom built and finished to McConaghy's uncompromising high quality standards under the expert guidance of interior designers
The interior is constructed using a mix of spray-painted surfaces and soft fabric liners
LOA 17.94m - 56'
BEAM 8.2m - 27'
DRAFT WITH DAGGERBOADS 1.20 - 2.5m 3'-10" to 8'-2" (manual control)
BRIDGE DECK CLEARANCE 1.02m - 3'-4"
DISPLACEMENT 10 tons
All figures are approximate
RIG
Carbon Fibre Mast & Boom - standard modulus carbon with clear carbon finish
Standing rigging - Dynaform including martingale
Halyards - Main 2:1, Topping Lift 1:1, Gennaker 2:1, Jib 1:1, 3 reefs
Furlers - Facnor electric furlers for Jib and Gennaker
Mast Height above Waterline - 26m
NORTH SAILS
Square Top Mainsail NPL Tour Xi Black Norlam Xi14 CRB
Self-tacking Furling Jib w/ Battens NPL Tour Xi Black Norlam Xi14 CRB
Easy Furling Gennaker NorLon NY150 (1.5 oz)
RBS Epoxy Battens
Upwind Sail Area 164m² - 1,765 sq.ft²
WINCHES
Harken 60.3 STEA 24v Electric Radial x 3
MAIN TRAVELLER
Harken electric line feed
3 Cabin or 4 Cabin Version
Three finish options - Chic Harmony, Natural Elegance, Modern Essence
AFT MAIN DECK
PMMA sliding door and window between saloon and aft deck
Transom steps, port and starboard, with discreet lighting
Deck and stairs finished with EVA foam
Clear removable panels to protect cockpit inside of helm stations
Courtesy lighting under furniture
Down lights
Settee with winch pods
Location for liferaft under aft settee
Floating lounge at port and starboard aft deck
Table on starboard aft cockpit, clear carbon finish
Cushions for seating area - Sunbrella & Weathermax foam
Handheld aft deck shower with hot/cold mixer tap
Two (2) Built in carbon davits (painted in black) with purchased system and clutch
Shore Power plug recessed in aft cockpit 32A
Two (2) hatches on aft cockpit port & stbd
Traveller
HELM STATIONS Port & Starboard
Stairs to helm stations
Two (2) McConaghy carbon racing helm seats with EVA foam
Two (2) McConaghy carbon steering wheels with ocean type carbon pedestals
Instruments mounted to aft of cabin top
Two (2) Lewmar ultra low deck hatches
SALOON/GALLEY
L- shaped settee
Fixed dining table(not foldable)
Under seating storage
Stairs to port & starboard hull
Two (2) electric fans
Headliners
Laminated soles
Electric blinds for side window
Manual blinds for forward window
Two (2) Lewmar size 3 flush mitre portlights for port windows
Two (2) Lewmar size 3 flush mitre portlights for STBD windows
Two (2) Lewmar Flush Mitre portlight 270x900 for fwd windows
Two USB sockets, type C sockets and one 220V/110V socket
Indirect headliner lighting
Lights at floor level
Courtesy lighting under floating furniture
GALLEY
Twin stainless steel sinks
One (1) Quokker flex tap
One (1) Smeg Induction hob (3 zones)
One (1) Smeg Built-in convection microwave oven
One (1) Isotherm Ocean single door fridge
One (1) Isotherm Ocean single door Freezer
One (1) USB socket , type C socket and Two (2) 220V/110V sockets
SIDE DECK & FORWARD DECK
Side decks covered with white nonslip solar panels
Two (2) Fwd side deck lockers PORT & STBD with Lewmar Ultra low deck hatches
Six (6) composite hatches for storage
One(1) carbon champagne and glass holder & One (1) carbon canapes tray
Sunbrella and weathermax foam cushions/sunbed for fwd deck
PORT HULL
Forward Guest Cabin
Seaward facing double berth
One (1) hanging locker inboard
One (1) low cupboard outboard
Two (2) reading lights
Indirect down lights
One (1) electric fan
One (1) Ultra low profile deck hatch Lewmar
One (1) Lewmar Size 1 Flush Mitre Portlights
Laminated sole
Hull liner and head liners
One USB socket and type C socket next to bedding
Mid Shower & Head
One (1) hanging locker inboard
One (1) low cupboard outboard
Shower with quality fittings
Painted sole, wall and ceiling in showering room
Tecma electric toilet
Vanity sink with cabinet
Mirror
Down lights
One (1) 220V/110V power socket
One (1) electric fan
Daggerboard box
One (1) escape hatch under stairs
One (1) Ultra low profile deck hatch Lewmar
One (1) Lewmar size 3 flush mitre portlights
Laminated sole, painted wall and ceiling
Aft Guest Cabin
Double berth
One (1) hanging locker inboard
One (1) low cupboards outboard
Two (2) reading lights
Indirect down lights
One (1) electric fan
One (1) ultra low profile deck hatch Lewmar
One (1) Lewmar size 1 flush mitre portlights
Laminated sole
Hull liner and head liners
One USB socket and type C socket next to bedding
STARBOARD HULL - 3 cabin version
FWD Shower & Head
Shower with quality fittings
Painted sole, wall and ceiling in shower
Tecma electric toilet
Twin sinks with cabinet
Mirror
Down lights
One (1) 220V/110V power socket
One (1) electric fan
One (1) ultra low profile deck hatch Lewmar
One (1) Lewmar size 3 flush mitre portlights
Laminated sole, painted wall and ceiling
Mid Storage Room
Inboard floating hanging lockers
Outboard low cupboards
Daggerboard box
Indirect down lights
One (1) electric fan
One (1) ultra low profile Deck hatch Lewmar
One (1) Lewmar size 3 flush mitre portlights
One (1) escape hatch under stairs
Laminated sole, hull liner and head liners
Aft Master Cabin
Double berth
Office desk with pivoting chair outboard
Hanging lockers inboard
Two (2) Reading lights
Indirect down lights
One (1) electric fan
One (1) ultra low profile Deck hatch Lewmar
One (1) Lewmar size 1 flush mitre portlights
Laminated sole
Hull liner and head liners
One USB socket and type C socket next to bedding
FOUR CABIN VERSION - PORT & STARBOARD HULLS ARE THE SAME CONFIGURATION
PROPULSION
Dual Oceanvolt ServoProp 15 Electric Propulsion system includes:
Electric motor 15 kW, ServoProp variable pitch sail drive x 2
Dual control Lever with display x 1
MG LFP battery 25.6V/304Ah/7800Wh (house use capacity included) x 8
MG master LV 24-48V/1000A x 2
MG smart link MX x 1
Victron energy Quattro-II 48/5000/70-50/50 230V x 1
Victron energy digital multi control GX x 1
Victron energy Cerbo GX x 1
Victron energy GX touch 70 x 1
Victron energy lynx distributor x 3
SMARTSOLAR MPPT 150/35 x 14
DCDC converter Scotty 3kW 48-12V x 1
AGM super cycle battery 60Ah x 1
Victron blue smart charger 230/12V- 15A x 1
Fischer Panda AGT-DC 11000-48V x 1
Generator start battery AGM super cycle battery 60Ah(12v 60AH) x 1
SOLAR POWER SUPPLY approx. 18kW
Hull outer topside composite solar (gloss finish)
Hull inner topside at fwd bow composite solar (gloss finish)
Gloss black, white translucent for side decks
Cabin top solar panels (gloss finish)
DC Power Panels
BEP switch remote control panel x 1
BEP navigation power panel x 1
DC-12V Loads panel x 1
AC POWER
Shore power inlet 32A x 1
Mastervolt mass GI 7 32A isolation transformer x 1
AC panel 8 circuits x 1
TANKAGE
Two (2) fuel tanks total 400L
Two (2) fresh water tanks total 400L
Two (2) black water tanks 60L each
PUMPS
One (1) Marco fuel transfer pump: VP45-N VANE PUMP 11 GPM-45L/MIN (12 VOLT)
Twelve (12) Rule automatic bilge pumps
One (1) Marco electronically-operated double fresh water pump 52L/min
FRESH WATER
One (1) Safiery Instant hot water system for galley and showers
One (1) Water maker 53Lph- Spectra CATALINA-340C 48V
One (1) Aqueous Ozone O3Clean detergent machine from tap water
One (1) Acuva Arrow UV-LED Water Purification System
One (1) Quokker Flex tap in galley
Two (2) 12V electric toilet Tecma Silence Plus 2G
Two (2) Fresh water Level Sensors
BLACK WATER
Two (2) 12V electric toilet Tecma Silence Plus 2G
Two (2) black water tanks 60L each
Two (2) Black water Level Sensors
NAVIGATION EQUIPMENT
B & G Equipment
Two (2) 12" Zeus™ S 12 chartplotters with C-MAP cartography
One (1) WS310 (wired) wind sensor with wind vane
One (1) DST 810 depth/speed/temp Sensor.
One (1) HALO20+ Radar
One (1) ZG100 Antenna with built in rate compass
One (1) B&G V60 marine VHF radio with DSC and AIS receive
One (1) Autopilot remote control B&G WR10 wireless remote with BT1 base stations
One (1) Navico 1720 VHF antenna
One (1) NEP-2 network expansion port
One (1) Jefa sprocket autopilot 12V
One (1) NAC-3 autopilot core pack
Internal Nav in fwd saloon includes B&G auto pilot controller a 4 inch B&G display, Oceanvolt throttle control with display, an Ipad 10.5inch
NAVIGATION LIGHTING
Tri-colour
Steaming Light
Anchor light
Spreader down lights
GROUND TACKLE & MOORING
Lewmar electric windlass V3
40kg galvanized Anchor
80m 10mm Galvanized chain
Chain counter
Anchor Bridle, 25mm with chain hook
Six (6) inflatable fenders (1500 x 450mm) with covers, portable electric pump and fender lines
Six (6) 18mm mooring lines, cored, spliced, looped and whipped
6 x Nomen folding cleats 250mm
Carbon fibre boat hook
SAFETY EQUIPMENT
Crash boxes and watertight bulkheads
Two Escape hatches in inboard hulls under stairs
Two (2) life jackets
Five (5) fire extinguishers
DECK HARDWARE
Composite stanchions
Dynema life lines
Two (2) deck water fillers
Two (2) deck fuel fillers
Two (2) deck waste pump-out
Foredeck trampolines in black
TENDER & SCOOTERS
McConaghy 3.6m RIB with aluminium hull inflatable fenders in ORCA Hypolon tube
7.5e Mercury electric outboard engine
Two (2) Maxfun foldable electric scooters
Ancasta are acting as brokers for the vendor who is not selling in the course of business unless otherwise stated. These details are prepared from information provided by the vendor and are intended only as a guide to give a fair description of the vessel but their accuracy cannot be guaranteed and they do not constitute part of any contract.
A prospective buyer is strongly advised to check the particulars and to have the vessel fully surveyed by a qualified marine surveyor. Details are supplied on the understanding that all negotiations shall be through Ancasta brokerages. This vessel is offered subject to prior sale, price change or withdrawal without notice. Please Note: where the vessel’s status shows as “Preliminary”, details of the vessel have not yet been confirmed by the Vendor.
Sign in or register an account to start saving boats
Don't have an account? Register
Broker Comments
The McConaghy Panther Cats deliver; excellent sailing performance, long range, autonomy, safety and stability. All carbon construction, powerful rig and sail plan deliver the performance. The expansive solar arrays and the OceanVolt ServoProp provide renewable power increasing range and autonomy. The DC generator assures power for night passages and calm conditions. The standard specification is comprehensive including: carbon spars, B&G navigations equipment, North Sails, 3.6m rib with electric motor plus two electric scooters All of this delivered in a yacht weighing 10 tons!
